dsh-comfyui-canvas

中文 · English

⚠️ DSH version compatibility: this plugin is built against DSH v0.1.1-rc.2 (conversation.view / split-rail contracts).

• ✅ Works with: DSH v0.1.0.x – v0.1.1.x (including release candidates)
• ⚠️ Not yet adapted: DSH v0.1.2+ (breaking client-side changes upstream may break the split-screen view; adaptation planned for v0.1.4)
• ❌ Non-official desktop wrappers (e.g. the community dsh-desktop) are not guaranteed compatible — they bundle an upstream version that may be ahead of or behind this plugin's baseline; rely on official DSH.

Embed your ComfyUI (local or cloud) as a split-screen canvas tab inside DeepSeek Harness Web, and merge DSH's LLM power with ComfyUI's generation into one visual creation platform — the agent sparks ideas, writes prompts and scripts right in the chat, applies them live to the canvas in front of you, and produces images, music, video, and 3D. From idea to finished output without ever leaving the conversation or switching front-ends:

• Canvas ops — compose and arrange pipelines, read/write workflows, edit nodes, wire links, run, tune parameters, and debug errors, all live and WYSIWYG on the exact canvas you are looking at
• Production tasks — batch parameter sweeps (batch_run) and automatic output-image retrieval back into the chat (get_outputs), powering multi-modal creative and batch generation across images, music, video, and 3D
• Environment upkeep — one-click launch of ComfyUI and one-click upgrade of the core plus every custom node (upgrade), keeping the stack healthy without interruption

This package is the DSH-side plugin, and it ships the ComfyUI-side bridge node too. For headless/scale workloads it can be paired with the official ComfyUI MCP server — see Canvas vs MCP.

Where this plugin fits: use it while building / tuning a workflow on the live canvas (the "IDE" role). For unattended / batch / production runs, hand the exported workflow to Comfy CLI (comfy-cli run_workflow) — it runs headlessly without a browser, which this canvas plugin deliberately does not do (the agent drives the canvas you are looking at; a closed browser means no runner). Export a workflow once with comfyui_export_api, then script it with the CLI at scale.

What you get

Install

1. Install the DSH plugin

dsh plugin add dsh-comfyui-canvas

Or from a GitHub checkout:

dsh plugin add github:wbin0001/dsh-comfyui-canvas

Or from a local checkout:

# in your DSH profile
pnpm add <path-to-this-package>

The bundled cordis.patch.yml mounts the plugin automatically (dsh.bundle.patch).

2. Install the ComfyUI bridge node

The agent tools talk to the ComfyUI page through a bridge (/dsh-bridge/*). The bridge node ships inside this repo at comfyui-bridge/ComfyUI-DSH-Canvas — copy it into ComfyUI's custom_nodes:

Windows (PowerShell / cmd):

# from this repo checkout:
Copy-Item -Recurse comfyui-bridge\ComfyUI-DSH-Canvas <ComfyUI>\custom_nodes\ComfyUI-DSH-Canvas

macOS / Linux (bash):

# from this repo checkout:
cp -r comfyui-bridge/ComfyUI-DSH-Canvas <ComfyUI>/custom_nodes/ComfyUI-DSH-Canvas

Or, after dsh plugin add, the installed package carries it too:

# Windows (PowerShell)
Copy-Item -Recurse (npm root -g)\dsh-comfyui-canvas\comfyui-bridge\ComfyUI-DSH-Canvas <ComfyUI>\custom_nodes\ComfyUI-DSH-Canvas

# macOS / Linux
cp -r $(npm root -g)/dsh-comfyui-canvas/comfyui-bridge/ComfyUI-DSH-Canvas <ComfyUI>/custom_nodes/ComfyUI-DSH-Canvas

Then restart ComfyUI and load the canvas page once (the injected bridge.js reports the graph and listens for commands).

3. Configure

Open Settings → ComfyUI Canvas and set the ComfyUI base URL (default http://127.0.0.1:8188), port, network mode, optional bridge token, launch command, and the right-side rail width.

The launch command differs by platform:

Security

The bridge (/dsh-bridge/*) is the only network surface this plugin adds to ComfyUI. Read this before exposing ComfyUI beyond loopback.

• Trust model. By default the bridge is unauthenticated, matching ComfyUI's own /prompt trust model — anyone who can reach the ComfyUI port can read the canvas, report state, and dispatch commands (load_workflow/run consume GPU). Commands are whitelisted on the frontend, so no arbitrary code execution is possible, but the surface is real.
• Bind to loopback. Keep ComfyUI on 127.0.0.1 unless you explicitly need LAN/cloud access. networkMode is informational; the actual bind is whatever ComfyUI was launched with (--listen).
• Optional shared token. Set a token in Settings → ComfyUI Canvas → Bridge Token AND launch ComfyUI with the same value in its own environment (DSH_BRIDGE_TOKEN=...). When the token is set, every agent-initiated request — reading the canvas, dispatching a command, polling its result — must present Authorization: Bearer <token>; the host side sends it automatically and the bridge rejects requests without it. The frontend's own status reporting (/report, result callbacks) stays open, since the injected page cannot hold the token; those endpoints only mutate the in-memory snapshot and never dispatch execution. Leave it empty on both sides for the default open behavior.
• Multiple tabs are safe. Commands are targeted at the last-reporting frontend (clientId), so several open ComfyUI tabs do not each execute a command.

Platform support

Works on Windows, macOS and Linux. The agent tools talk to ComfyUI over plain HTTP (/dsh-bridge/*), so nothing platform-specific lives in the plugin itself — only the copy command and the ComfyUI launch command differ, and both are documented above.

Usage

1. Open a conversation, switch to the ComfyUI tab — the canvas splits on the left, chat on the right.
2. Ask the agent to do canvas work: "read the current workflow", "set KSampler seed to 42", "check the canvas for errors", "run it".
3. The agent reads comfyui_config first, so it knows it's on the canvas and stays focused on canvas operations.

Conversation → canvas

Content the agent generates in the chat — images and text — can become ComfyUI workflow node inputs directly, closing the loop from conversation idea to canvas output:

• comfyui_attach_image: upload a local image into ComfyUI's input/ and optionally point a LoadImage node at it. Uses ComfyUI's native /upload/image (not the bridge) — the host reads and uploads the file from the agent's own machine, which matters when the DSH machine and the ComfyUI machine differ (cloud deployments).
• comfyui_inject_text: write text to a node's widget; or create a new source node, set its value, and connect it to a target input — "conversation text as a wirable source". A one-step wrapper over add_node + set_param + connect; set_param alone suffices when only an existing widget changes, and inject_text is for "create a new source and wire it".
• comfyui_export_api: export the live canvas as API-format workflow JSON (the format /prompt and comfy-cli run_workflow consume), bridging canvas → MCP headless runs.

Architecture boundary: file transfer (image → input/) goes through the host + native API; canvas node ops go through bridge commands; reading results goes through native /history + /view — three layers that never mix.

Canvas vs MCP — two ways to drive ComfyUI

This plugin is the canvas driver: it sees and edits the live canvas the user is looking at (add nodes, wire links, tweak widgets, run, fetch the run's output images via comfyui_get_outputs, sweep parameters via comfyui_batch_run). It never needs a saved workflow file.

For pipeline-style / headless workloads, ComfyUI's official Comfy CLI (comfy-cli) is a complementary tool. It is a standalone Python CLI (installed via pip install comfy-cli, and can also expose an MCP server) — not a DSH plugin, so it is used separately from this plugin rather than mounted into the DSH profile. It covers capabilities this canvas plugin deliberately does not re-implement:

Recommended split: use this plugin while you are building/tuning a workflow on the canvas; use the Comfy CLI once you want to run the same graph headlessly at scale (batch pipelines, templates, model management, hosted models). They talk to the same ComfyUI instance and can be used side by side. Install the Comfy CLI with:

pip install comfy-cli   # standalone CLI, not a DSH plugin — see https://github.com/Comfy-Org/comfy-cli

Requirements

• DeepSeek Harness Web (DSH), Node ^22.19.0 || >=24
• ComfyUI running (local by default at 127.0.0.1:8188; for a cloud instance, deploy the bridge node there and make sure DSH can reach it) with the bridge node installed
• A browser tab with the ComfyUI page open (the canvas tab loads it automatically)

Development

npm run check   # node --check both lib files

The plugin lives in the DSH profile under node_modules/dsh-comfyui-canvas; edit lib/index.js (host tools) and lib/client.js (web client), then restart DSH.

Repository layout

dsh-comfyui-canvas/
├── cordis.patch.yml          # DSH bundle layer (auto-mount)
├── comfyui-bridge/           # ComfyUI-side bridge node (self-contained)
│   └── ComfyUI-DSH-Canvas/
│       ├── __init__.py       # /dsh-bridge/* HTTP routes on the ComfyUI server
│       └── entry/bridge.js   # injected frontend: reports graph + runs commands
├── lib/
│   ├── index.js              # DSH host: 19 canvas tools + 4 built-in skills
│   └── client.js             # DSH web: canvas tab / settings / rail polish
├── LICENSE
├── README.md
└── package.json

The bridge is the only ComfyUI-side dependency. It exposes /dsh-bridge/workflow|report|command|result and is injected into the ComfyUI page via app.registerExtension; without it the agent tools cannot reach the canvas.

Known issues

• comfyui_reload currently supports Windows only (uses netstat/taskkill); on macOS/Linux it fails loud instead of pretending, restart ComfyUI manually there.
• The former "node previews missing after a run" is fixed in v0.1.1: removed the iframe's referrerpolicy="no-referrer" to match the native tab environment, and bridge.js now listens to ComfyUI's executed event to force a canvas redraw.
